NETWORK    Technology
GSM / CDMA / HSPA / EVDO / LTE
LAUNCH    Announced    2016, September 07. Released 2016, September 16
Status    Discontinued
BODY    Dimensions    138.3 x 67.1 x 7.1 mm (5.44 x 2.64 x 0.28 in)
Weight    138 g (4.87 oz)
Build    Glass front (Corning-made glass), aluminum back, aluminum frame
SIM    Nano-SIM
     IP67 dust/water resistant (up to 1m for 30 min)
Apple Pay (Visa, MasterCard, AMEX certified)
DISPLAY    Type    Retina IPS LCD, 625 nits (typ)
Size    4.7 inches, 60.9 cm2 (~65.6% screen-to-body ratio)
Resolution    750 x 1334 pixels, 16:9 ratio (~326 ppi density)
Protection    Ion-strengthened glass
     3D Touch display & home button
PLATFORM    OS    iOS 10.0.1, upgradable to iOS 15.7
Chipset    Apple A10 Fusion (16 nm)
CPU    Quad-core 2.34 GHz (2x Hurricane + 2x Zephyr)
GPU    PowerVR Series7XT Plus (six-core graphics)
MEMORY    Card slot    No
Internal    32GB 2GB RAM, 128GB 2GB RAM, 256GB 2GB RAM
     NVMe
MAIN CAMERA    Single    12 MP, f/1.8, 28mm (wide), 1/3", PDAF, OIS
Features    Quad-LED dual-tone flash, HDR
Video    4K@30fps, 1080p@30/60/120fps, 720p@240fps
SELFIE CAMERA    Single    7 MP, f/2.2, 32mm (standard)
Features    Face detection, HDR, panorama
Video    1080p@30fps
SOUND    Loudspeaker    Yes, with stereo speakers
3.5mm jack    No
COMMS    WLAN    Wi-Fi 802.11 a/b/g/n/ac, dual-band, hotspot
Bluetooth    4.2, A2DP, LE
Positioning    GPS, GLONASS, GALILEO, QZSS
NFC    Yes
Radio    No
USB    Lightning, USB 2.0
FEATURES    Sensors    Fingerprint (front-mounted), accelerometer, gyro, proximity, compass, barometer
BATTERY    Type    Li-Ion 1960 mAh, non-removable (7.45 Wh)
Talk time    Up to 14 h (3G)
MISC    Colors    Jet Black, Black, Silver, Gold, Rose Gold, Red
Models    A1660, A1778, A1779, A1780, A1853, A1866, iPhone9,1, iPhone9,3
SAR    1.19 W/kg (head)     1.19 W/kg (body)
SAR EU    1.38 W/kg (head)     1.34 W/kg (body)
Price    About 180 EUR
TESTS    Performance    Basemark OS II 2.0: 3416
Display    Contrast ratio: 1603:1 (nominal), 3.964 (sunlight)
Camera    Photo / Video
Loudspeaker    Voice 67dB / Noise 73dB / Ring 75dB
Audio quality    Noise -92.4dB / Crosstalk -80.9dB
